Climax CM6200 - Igure A-33. Air Control Assembly for Pneumatic Feed (P;N 63156)

Page 152 CM6200 Operating Manual
FIGURE A-33. AIR CONTROL ASSEMBLY FOR PNEUMATIC FEED (P/N 63156)
PARTS LIST
DESCRIPTION
PART No.
QTY
ITEM
WASHER THRUST .75 OD X .312 ID X .03
1077011
FTG REDUCER BUSHING 1/2 NPTM X 1/4 NPTF STEEL1292012
FTG QUICK COUPLER 1/2B 1/2NPTF FEMALE AIR
1320813
FTG QUICK COUPLER 1/4B 1/4 NPTF FEMALE AIR2849414
FTG ELBOW 1/4 NPTM X 1/4 NPTM 90 DEG
305022
5
FTG QUICK COUPLER 3/8B 1/4 NPTM MALE AIR3093616
LABEL DIRECTION OVAL HANDLE BALL VALVE
3577217
FTG QUICK COUPLER 3/8B 1/2 NPTM FEMALE AIR5512618
VALVE BALL 1/4 NPTF X 1/4 NPTF VENTED OVAL HANDLE
5920319
FTG TEE 1/4 NPTF (3)59695110
HOSE ASSY 801 1/4 X 1/4 NPTMS ENDS X 600
63155211
REGULATOR PNUE. 2-40 PSI DIAL SET SEMI-PRECISION 1/4 NPTF X 1/4 NPTF
71317112
ASSY PNEUMATIC FILTER & VALVE WITH STAND
97742113
12
3
2
5
9
7
1
11
4
11
5
10
6
8
13
