Climax CM6200 - Igure A-24. Milling Head Extension Assembly (P;N 65840)

P/N 63674, Rev. 9 Page 143
F
IGURE A-24. MILLING HEAD EXTENSION ASSEMBLY (P/N 65840)
SCREW M12 X 1.75 X 110 MM SHCS
6116425
BOLT EYE M10 X 1.5 X 17MM LG
5962514
SCREW M12 X 1.75 X 55 SHCS4607862
EXTENSION MILLING HEAD6583911
PARTS LIST
DESCRIPTIONPART No.QTYITEM
5
4
2
1
