Climax CM6200 - Igure A-13. Machining Arm Milling Head Tram Assembly (P;N 63124)

Page 132 CM6200 Operating Manual
FIGURE A-13. MACHINING ARM MILLING HEAD TRAM ASSEMBLY (P/N 63124)
PARTS LIST
DESCRIPTION
PART No.
QTY
ITEM
PIN DOWEL 1/2 DIA X 1-1/21183241
SCREW M12 X 1.75 X 25mm SHCS4209462
PLATE MILL TRAMMING CM6200
6292113
PIN DOWEL 3/4 DIA X 1-1/4
6355714
2
3
4
1
