Grinding option
P/N 63674, Rev. 9 Page 81
11. Adjust the speed control knob on the pendant until the turntable is rotating
at the necessary speed.
To protect yourself from flying chips, wear eye protection while
operating the machine.
12. To stop machine rotation, press the stop button for the circular mill control
pendant.
13. Repeat cutting passes as required. For very fine finishes make several
rough cuts and one fine finish cut.
Move the cutter radially off the work piece between cuts or when the cut is com-
plete.
4.4 GRINDING OPTION
4.4.1 Grinding attachment setup
The grinding attachment uses the same mount adapter as the single point tool
option. See the exploded views (Figure A-16 on page 135, Figure A-17 on page
136, or Figure A-18 on page 137) for more information about the parts needed for
grinding.
Do the following to set up the grinding attachment:
1. Set up the machine in the flange, according to the mounting instruction in
Section 3.4 on page 25.
2. Install the grinding head to the arm (see Section 4.5.2 on page 89 for
instructions on replacing the milling head).
3. Use the screws provided to attach the grinder to the face of the tool head.
4. Attach hoses from the grinding attachment to the PCU.
Only make a maximum of two or three passes in either direction. Then
reverse direction to prevent binding up the hoses.
