P/N 63674, Rev. 9 Page 129
PARTS LIST
DESCRIPTION
PART No.
QTY
ITEM
SCREW DRIVE #2 x 1/4 HOLE SIZE .089
10588128
1
(NOT SHOWN) CONTAINER SHIPPING FLAT ROOF 20 X 8.75 X 10.5
19700
1
2
PLATE MASS CE29152323
SCREW M20 X 2.5 X 70 MM SHCS5619232
4
WELDMENT STANDOFF 12.5 FF8200577248
5
WELDMENT STANDOFF 17.5 FF82005785186
WELDMENT STANDOFF 27.5 FF8200578528
7
SCREW M20 X 2.5 X 40MM SHCS58203968
LABEL WARNING LIFT POINT ROUND 1.5"
59039329
SCREW M8 X 1.25 X 16MM BHSCS598271610
PLATE CENTERING OD MOUNT FF8200607518
11
PLATE WASHER OD MOUNT FF820060752812
STUD HOLD DOWN M24 OD MOUNT FF820060753813
STANDOFF 5 INCH OD MOUNT FF8200607558
14
SCREW M24 X 3.0 X 60MM SSSFP6075648
15
NUT M24 X 3.0 FLANGED60757
8
16
SHIELD OD MOUNT FF8200614338
17
LEG VERTICAL SUPPORT OD MOUNT CM620062687818
SCREW M20 X 2.5 X 170MM SHCS639353219
(NOT SHOWN) LIFTING EYE M6 X 1 X 12 THREAD 19 ID 460 LBS 210 KG
63954
4
20
LABEL WARNING - LIFT SUB ASSY ONLY GRAPHIC 2 X 3 793853221
LABEL CAUTION - TORQUE 150 FT-LBS (203 N-M) GRAPHIC 3 X 1.7
821573222
LABEL WARNING - HAND CRUSH GRAPHIC 1.95"
82163823
LABEL WARNING - BODY CRUSH GRAPHIC 1.95"
82164824
LABEL DANGER - GUARDS OD MOUNT GRAPHIC 4 X 282172825
5
14
6
7
8
8
22
21
9
1
3
19
23
24
10
17
13
15
4
16
15
12
11
25
