Climax CM6200 - Point Machining; Rotary Table Speeds Using Hydraulic Motors When Single-Point Machining

Features and options
P/N 63674, Rev. 9 Page 13
option is compatible with all options.
Contact CLIMAX for more information on these functions and options, or if a spe-
cific machine application requires additional options or accessories.
2.1.3 Rotary table speeds using hydraulic motors when single-point machin-
ing
Table 2-1 shows the effective maximum rotary speeds for each available hydraulic
motor when single-point machining (that is, flange facing).
TABLE 2-1. ROTARY TABLE SPEEDS WHEN SINGLE-POINT MACHINING
Motor
P/N
Hydraulic motor
displacement
Maximum speed
a
at
20 gpm
a.Maximum rotary table RPM
Maximum speed
b
at
10 gpm
b.Maximum rotary table RPM
60 Hz HPU 50 Hz HPU 60 Hz HPU 50 Hz HPU
46950 11.9 in
3
(195.0 cm
3
) 32 rpm 26 rpm 16 rpm 13 rpm
46375 14.9 in
3
(244.2 cm
3
) 25 rpm 20 rpm 13 rpm 10 rpm
46549 18.7 in
3
(306.4 cm
3
) 20 rpm 16 rpm 10 rpm 8 rpm
46550 24.0 in
3
(393.3 cm
3
) 16 rpm 13 rpm 8 rpm 6.5 rpm
48968 29.8 in
3
(488.3 cm
3
) 13 rpm 10 rpm 6 rpm 5 rpm
