Specifications
P/N 63674, Rev. 9 Page 19
2.4 SPECIFICATIONS
2.4.1 Weight specifications
2.4.2 Hydraulic motor specifications
Refer to Figure 2-6 on page 20 for the maximum speeds, pressures, and flow rates
for the various hydraulic motors. Do not exceed these limits or the limits of the
HPU.
Exceeding the designated parameters of the hydraulic system can
cause the machine to malfunction, leading to damage to the machine or
injury to personnel.
TABLE 2-4. SUBASSEMBLY WEIGHTS
Subassembly Part Number Weight
Rotary table: 62028 3,493 lb (1584 kg)
Machining arm: 72676 1,310 lb (594 kg)
Counterweight arm: 62031 1,590 lb (721 kg)
12" ID mount leg section: 62038 70.5 lb (32 kg)
17.5" ID mount leg section: 62038 90.4 lb (41 kg)
27.5" ID mount leg section: 62038 110 lb (50 kg)
5" OD mount leg section: 60755 25.5 lb (11.6 kg)
12.5" OD mount leg section: 57724 66.5 lb (30.2 kg)
17.5" OD mount leg section: 57851 80.3 lb (36.4 kg)
27.5" OD mount leg section: 57852 108 lb (49.0 kg)
Milling head: 72277 112 lb (55 kg)
