Features and options
Page 12 CM6200 Operating Manual
The machine is easily mounted into place by chucking bolts in the inner diameter
of the working surface. The machine can easily be leveled and centered into place.
The machining arm rotates about the bearing allowing the milling head, (or the
optional grinder, or single point tooling) to cut smoothly.
For milling (or optional grinding) applications, the radial and axial travel can be
manually actuated with a hand wheel. The milling head can rotate a full 360° with
an optional swivel plate.
2.1.1 Features
The CM6200 includes the following features:
Kingpin clearance – 25" (635 mm) diameter for dock and construction
cranes.
Rigid rotational drive system – Large diameter and preloaded bearing
provides optimal rigidity during machining.
Adjustable turning and counterweight arms – Both the machining arm
and counterweight arm can be adjusted for the desired swing clearance and
machining range. The counterweight is recommended, but not required for
horizontal machining applications.
Chucking design – Tubular rigid chucking system with a level in place and
adjustable feet designed for simple and speedy setup.
Modular design – Allows many of the machine components to be removed
to facilitate easier setup and storage.
Touch screen controls – The servo option comes complete with full touch
screen pendant controls.
2.1.2 Available machine options
The CM6200 is configurable for many specific machining needs. The following
are available options:
ID mount – This machine can be mounted on the inside of the workpiece
using chucking bolts on the inner surface.
OD mount – This machine can be mounted to the outside diameter of the
workpiece using our optional OD mount kit, and customer-supplied outrig-
gers or scab plates.
ID and OD mount – This machine can be mounted to the workpiece using a
combination of the ID and OD machines.
Face mounting – A face mount kit is available to allow mounting the chuck
directly to the work piece or a customer supplied mounting apparatus.
Single point machining – Provides flange facing capabilities at larger
diameters. This option is compatible with all options.
Grinding attachment – Provides much finer surface finish capabilities. This
