P/N 63674, Rev. 9 Page 123
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
PUSH-ON TRIM SEAL - FLEXIBLE SEGMENTED CORE
4562311
SCREW M16 X 2.0 X 55mm SHCS
46222442
SCREW M16 X 2.0 X 80 SHCS
58106483
LABEL WARNING LIFT POINT ROUND 1.5"
59039164
ASSY BRG AND GEAR KAYDON 66 OD PRELOADED
6156515
HUB CHUCK CM6200
6196716
PLATE TABLE ROTARY CM6200
6260017
HOIST RING M24 X 3 X 38MM 70 ID X 130 OD 225 OAL 9250 LBS 4200 KG SWIVEL62606
4
8
1 TORQUE SPECIFICATION: CM6200 BEARING TO CHUCK
LABEL BOLT HOLES FROM 1 TO 48 CLOCKWISE AROUND THE BEARING
TIGHTEN THE BOLTS USING THE FOLLING PATTERN IN THREE STAGES 70 FT-LBS,
140 FT-LBS, 200 FT-LBS. NOTE: TORQUE VALUES ARE FOR LUBRICATED
FASTENERS. ENSURE TO USE BLUE LOCTITE DURING ASSEMBLY.
1 - 25 - 13 - 37 7 - 31 - 19 - 43 4 - 28 - 16 - 40 10 - 34 - 22 - 46
2 - 26 - 14 - 38 3 - 27 - 15 - 39 5 - 29 - 17 - 41 6 - 30 - 18 - 42
8 - 32 - 20 - 44 9 - 33 - 21 - 45 11 - 35 - 23 - 47 12 - 36 - 24 - 48
2 TORQUE SPECIFICATION: CM6200 TOP PLATE TO BEARING
LABEL BOLT HOLES FROM 1 TO 44 CLOCKWISE AROUND THE TOP PLATE
TIGHTEN THE BOLTS USING THE FOLLING PATTERN IN THREE STAGES 70 FT-LBS,
140 FT-LBS, 200 FT-LBS. NOTE: TORQUE VALUES ARE FOR LUBRICATED
FASTENERS. ENSURE TO USE BLUE LOCTITE DURING ASSEMBLY.
1 - 23 - 12 - 34 6 - 28 - 17 - 39 3 - 25 - 14 - 36 8 - 30 - 19 - 41
4 - 26 - 15 - 37 9 - 31 - 20 - 42 2 - 24 - 13 - 35 7 - 29 - 18 - 40
5 - 27 - 16 - 38 10 - 32 - 21 - 43 11 - 33 - 22 - 44
