Single-point option
P/N 63674, Rev. 9 Page 85
FIGURE 4-33. FEED BOX DETAIL
TABLE 4-7. FEED BOX DETAIL IDENTIFICATION
Number Component
1 1/8" tubing from port 3
2 1/4" tubing from air valve
3 Mounts to the ball screw on the end of the turning arm
4 Mounting arrow shows the feed direction
MOUNTS TO THE BALL
SCREW ON THE END
OF THE TURNING ARM
MOUNTING
ARROW
SHOWS FEED
DIRECTION
1/8" TUBING
FROM PORT 3
1/4" TUBING
FROM AIR VALVE
3
1
2
4
