Climax CM6200 - Page 145

P/N 63674, Rev. 9 Page 127
F
IGURE A-8. ADJUSTABLE CHUCK FOOT ASSEMBLY (P/N 89730)
PARTS LIST
DESCRIPTION
PART No.
QTY
ITEM
RING O 3/32 X 9/16 ID X 3/4 OD
1061121
WASHER THRUST .750 ID X 1.250 OD X .0312
1173912
WASHER THRUST 1.250 ID X 1.937 OD X .060
1666613
PIN DOWEL 3/16 DIA X 1-1/4
1973524
SCREW M16 X 2.0 X 200 SHCS
442272
5
SCREW M8 X 1.25 X 10mm SSSDP
4425726
SCREW M16 X 2.0 X 40mm SHCS
4490547
SCREW M16 X 2.0 X 55mm SHCS
4622228
SCREW M16 X 2.0 X 80 SHCS5810629
WASHER SPRING WAVE 1.235 OD X .961 ID X .01458244110
JAW ADJUSTER CM620063582111
BASE ADJUSTER CM620063583112
JAW SCREW CM620063584113
SCREW M30 X 1.5 X .875 HOLLOW LOCK MOD
63585114
FINGER SETUP EXTENSION CM6200
63586115
RESTRAINT SAFETY WELD PLATE CM6200
63842116
CLAMP INTERNAL FLANGE CM6200
63853117
SCREW M16 X 2.0 X 120 SHCS
64086218
SCREW M16 X 2.0 X 160 SHCS
64087219
SS OO C C S
1
7
15
11
4
2
6
16
8
57
89
17
14
13
10
12
3
