Climax FF6300 - Igure A-4. Pneumatic Conditioning Unit MM Low Pressure Drop out (P;N 78264)

Page 84 FF6300 Operating Manual
FIGURE A-4. PNEUMATIC CONDITIONING UNIT 1/2" (13 MM) LOW-PRESSURE DROP-OUT (P/N 78264)
ASSEMBLED
SCALE 1 : 5
