Climax FF6300 - Igure A-2. Air Control Assembly for Pneumatic Feed (P;N 87941)

P/N 80679, Rev. 10 Page 81
FIGURE A-2. AIR CONTROL ASSEMBLY FOR PNEUMATIC FEED (P/N 87941)
PARTS LIST
DESCRIPTIONP/N:QTYITEM
WASHER THRUST .75 OD X .312 ID X .031077011
FTG QD NIPPLE 1/2B 1/2 NPTM PNEUMATIC
1320912
FTG QUICK COUPLER 1/2B 1/2 NPTM FEMALE AIR
1661013
FTG QUICK COUPLER 3/8B 1/4 NPTF FEMALE AIR
3569014
LABEL DIRECTION OVAL HANDLE BALL VALVE
357721
5
VALVE BALL 1/4 NPTF X 1/4 NPTF VENTED OVAL HANDLE
5920316
ASSY PNEUMATIC FILTER & VALVE WITH STAND
593291
7
HOSE ASSY 801 1/4 X 1/4 NPTMS ENDS X 180
5933018
FTG ADAPTER 1/2 NPTF X 1/4 NPTM
7802519
6
4
8
5
1
2
3
7
9
