Page 96 FF6300 Operating Manual
FIGURE A-16. OD MOUNT CLAMP KIT (P/N 80622)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
NUT 3/4-10 STDN ZINC PLATED
1019731
WASHER THRUST .750 ID X 1.250 OD X .123
1019832
ROCKER CHAIN CLAMP
1020633
CASTING BLOCK CLAMP SMALL155043
4
CASTING -BLOCK CLAMP158353
5
CHAIN WRENCH 3/4 PITCH .240 DIA PIN (3 LENGTHS AT 57")
273661716
BOLT - CHAIN CLAMP
273853
7
SCREW M6 X 1.0 X 20 SHCS
35009128
SCREW M12 X 1.75 X 30mm SHCS
4069769
SCREW M8 X 1.25 X 30 OAL X 10 THD L STAINLESS74632610
FOOT OD CLAMP MOUNT80623311
SETUP FINGER OD MOUNT80624312
GRIPPER HSS 25mm SQ M6
823151213
6
4
9
11
2
3
1
9
5
7
6
10
12
8
13
