2.2 RIGGING AND LIFTING INFORMATION
TABLE 2-1. WEIGHTS
lbs kg
Total machine weight ID chuck
*
* Machine weights are operating weights.
473 215
Total machine weight OD mount
†
† OD mount weights are for the complete machine.
773 353
ID chuck 187 85
Main body assembly 103 47
Turning arm with feed box 101 46
Counterweight assembly 77 35
Pneumatic motor 10 5
Hydraulic motor 10 4.5
Wooden shipping crate 177 80
Metal shipping container 220 100
Accessories
Backfacing attachment 37 17
OD mount 493 224
OD mount chain clamp 36 16
OD mount wooden shipping crate
(no metal shipping container)
123 56
TABLE 2-2. SHIPPING WEIGHTS
lbs kg
ID chuck in wooden crate 650 294
ID chuck in metal container 693 314
OD mount in wooden crate 616 280
TABLE 2-3. SHIPPING DIMENSIONS
Width
*
* All dimensions include handles and latches if applicable.
Depth Height
Wooden crate 63.5" (1613 mm) 26" (660 mm) 25.75" (654 mm)
Metal container 60.16" (1528 mm) 24.16" (614 mm) 26.86" (682 mm)
OD mount wooden crate 47.25" (1200 mm) 42.25" (1073 mm) 19.75" (502 mm)
