Page 92 FF6300 Operating Manual
FIGURE A-12. COUNTERWEIGHT ARM ASSEMBLY (P/N 80324)
PARTS LIST
DESCRIPTIONP/N:QTYITEM
RING O 1/8 X 1-3/16 ID X 1-7/16 OD1046611
BALL NYLON 5/16 DIA2650612
SCREW M10 X 1.5 X 20MM SSSCP4967913
BAR COUNTERWEIGHT 23 IN7979114
COUNTERWEIGHT797921
5
CLAMP COLLAR 30mm ID X 55mm OD X 20mm 2 PIECE WITH DAMPER8221816
2
3
5
4
6
1
