Climax FF6300 - Igure A-1. Feed Box Pneumatic Manual Feed Adjust (P;N 87326)

Page 80 FF6300 Operating Manual
FIGURE A-1. FEED BOX PNEUMATIC MANUAL FEED ADJUST (P/N 87326)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
PIN DOWEL 3/16 x 3/4
1176311
DETENT PLUNGER BALL 1/4-20 X .531
1306112
RING SNAP 1 OD SPIRAL HEAVY DUTY
1424113
FTG ADAPTER 1/8 NPTM X 1/4 TUBE F PRESTOLOCK NICKEL PLATED184392
4
SCREW 3/8-16 X 2 KHS (KNURLED HEAD)259531
5
BRG ROLLER CLUTCH 1 X 1.312 X .6252595726
SEAL 1.000 ID X 1.312 OD X .125 HM14 LIP259592
7
SPRING COMP .48 OD X .051 WIRE X .882861818
SCREW M5 X .8 X 16 SHCS
3511349
ARM RATCHET
57491110
BRG NEEDLE 1.0 X 1-5/16 X .625
57530111
SCREW M5 X .8 X 40mm SHCS
57541412
HOUSING PNEUMATIC FEED BOX REMOTE ADJUSTABLE
58435113
CLEVIS DOUBLE 6MM PIN 3/8-24 SHAFT
58450114
BUSHING DRIVE DOUBLE ENDED
58451115
SHAFT FEED
58519116
SCREW 6MM DIA X 20MM X M5 X 0.8 SHLDCS
58588117
SCREW M6 X 1.0 X 60mm SHCS
59156218
PLATE FEED ADJUST
87322119
NUT 3/8-16 ACON HS G8 ZINC
87411120
CYLINDER AIR 40MM DIA 10MM STROKE DOUBLE ACTING
87842121
15
20
1714
21
12
19
9
5
4
8
13
3
13
6
18
11
1
2
6
10
16
7
7
