FIGURE A-22. SURFACE MOUNT ASSEMBLY (P/N 82309)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
SCREW M10 X 1.5 X 30mm SHCS
1821481
SCREW M16 X 1.5 X 20mm SSSFP
3464382
SCREW M12 X 1.75 X 20mm SSSFP
4318643
BLOCK TACK WELD
7954544
WASHER 3/8 FLTW HARDENED 1 OD X .2 THK BLACK OXIDE FINISH
7992785
PLATE SURFACE MOUNT FF6300
8064716
6
1
5
2
3
4
