Climax FF6300 - Igure A-25. Bypass Assembly for Set up of Hydraulic Machine (P;N 83154)

P/N 80679, Rev. 10 Page 105
FIGURE A-25. BYPASS ASSEMBLY FOR SET UP OF HYDRAULIC MACHINE (P/N 83154)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
FTG ELBOW 7/8 SAEM ORING X 1/2 NPTF 90 DEG
2041121
FTG DUST PLUG 1/2 QD COUPLER
2797722
FTG QUICK COUPLER FEMALE 60 SERIES 1/2B X SAE-10F
4061523
FTG NIPPLE 1/2 NPTM X 2-1/2 STEEL BLACK
8315314
2
3
1
2
3
1
4
