Climax FF6300 - Igure A-13. Backface Attachment Assembly (P;N 80362)

P/N 80679, Rev. 10 Page 93
FIGURE A-13. BACKFACE ATTACHMENT ASSEMBLY (P/N 80362)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
SCREW M6 X 1.0 X 20 SHCS
3500961
SCREW M10 X 1.5 X 100 SHCS CLASS 12
3726242
SCREW M10 X 1.5 X 80mm SHCS
5898523
SCREW M10 X 1.5 X 90MM SHCS60031
44
PLATE DOVE CIRCULAR798261
5
(NOT SHOWN) SHIM 1.8 ID X 3.2 OD .001 THICK
80419AR6
(NOT SHOWN) SHIM 1.8 ID X 3.2 OD .002 THICK
80420AR
7
(NOT SHOWN) SHIM 1.8 ID X 3.2 OD .005 THICK
80421AR8
PLATE LOWER BF ATTACHMENT
8049219
PLATE UPPER BF ATTACHMENT80493110
PLATE CLAMP BF ATTACHMENT80494111
PLATE CLAMP THREADED BF ATTACHMENT80495112
3
4
2
11
10
12
9
1
5
