Climax FF6300 - Igure A-21. Leveling Foot MM Assembly (P;N 81977)

P/N 80679, Rev. 10 Page 101
FIGURE A-21. LEVELING FOOT 4" (102 MM) ASSEMBLY (P/N 81977)
PARTS LIST
DESCRIPTIONP/N:QTYITEM
WASHER THRUST 1 ID X 1.562 OD X .060
1014411
SCREW M6 X 1.0 X 35mm SHCS
3550412
SCREW M8 X 1.25 X 20mm SHCS
5045843
WASHER SPRING WAVE .26 ID X .43 OD
7236114
SCREW JACKING LEVELING 1-5/8-12
798291
5
BASE ADJUSTER
8042716
JAW LEVELING
804281
7
SCREW MODIFIED M20 X 1.5 X 12.7MM HOLLOW LOCK
8043018
CAP END 4.00 DIA THREADED
8197819
NUT JACKING LOCK 1-5/8-12
81979110
SETUP FINGER
81980111
SCREW M8 X 1.25 X 40MM SHCS CAPTIVE 10 THD STAINLESS
82196212
10
9
3
12
12
11
8
7
2
4
6
1
5
