FIGURE A-3. PNEUMATIC FILTER AND VALVE WITH STAND ASSEMBLY (P/N 59329)
ASSEMBLED VIEW
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
WASHER 5/16 FLTW SAE
1348961
NUT 5/16-18 NYLON INSERT LOCKNUT
1972962
SCREW 5/16-18 X 5/16 SSSFP
27895163
BRACKET 90DEG JOINER MODU-TEK
4676144
ENDCAP 1 X 1 FOR 1.63SQ MODU-TEK EXTRUSION467646
5
BRACKET 1X2 SLOT HALF WEB LEFT MODU-TEK
4676516
VALVE SHUT OFF VS22 SERIES
467771
7
BRACKET 1X2 SLOT HALF WEB RIGHT MODU-TEK
4678318
1.63 X 1.63 X 3.375L MODU-TEK EXTRUSION
4680229
SCREW M5 X 0.8 X 12MM BHCS BLACK FINISH53617210
SCREW 5/16-18 X 3/4 T-BOLT
59436611
1.63 X 1.63 X 7.00L MODU-TEK EXTRUSION
59437412
RING O 2mm X 23mm ID X 25mm OD
59442113
NUT PLATE M5 X .08 AND 5/16-32 .75 X 1.25 X .25
59705214
SCREW M5 X 0.8 X 40MM SHCS
59754215
FILTER/REGULATOR PARTICULATE 1/2NPTF METAL BOWL GLASS
78054116
PRESSURE GAUGE, 0-160 PSI, 1/8 NPT CENTER BACK MOUNT
83486117
2
1
11
9
4
12
7
10
13
15
8
6
14
4
3
5
9
16
17
