INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page A.23
November 21, 2008
Oct.
Label
429
Parameter
Signal
Format
Units
Pos.
Sense
Range (r)
Sig.
Bits
Res. (r)
SDI
Pres.
Nom. Tx
(a)
145 (e) Horizontal
Vel. FOM
BNR Knots (c) 4096 18 0.015625 Y 100
150 UTC (j) BNR HR:
MIN:S
(c) 23:59.59 17 1 Second Y 100
156 Approach
Selection
Status (j)
DISC N/A N/A N/A N/A N/A Y 200 (m)
157 Input
Discrete
Status (j)
DISC N/A N/A N/A N/A N/A Y 1000 (m)
162 Dest ETA (j) BNR HR:
MIN
23:59 11 1 Min Y 500
163 Alt ETA (j) BNR HR:
MIN
23:59 11 1 Min Y 500
165 Vertical
Velocity
BNR Ft/min UP ±32,768 18 0.125 Y 100
166 N/S Velocity BNR Knots N ±4096 18 0.015625 Y 100
171 Vertical
Proportional
Deviation (o)
BNR DDM Fly
Down
±0.8 12 (t)
≅1.95E-4
Y 50 (f)
173 Lateral
Proportional
Deviation (o)
BNR DDM Fly
Right
±0.4 12 (t)
≅9.77E-5
Y 50 (f)
174 E/W Velocity BNR Knots E ±4096 18 0.015625 Y 100
177 Distance to
LTP/FTP
BNR NM (c) +512 (w) 16
≅7.81E-3
Y 100
226 Data Loader
(k)
ISO#5 N/A N/A N/A N/A N/A N/A N/A
227 Command
Summary
Word (j)
DISC N/A N/A N/A N/A N/A Y On Call
232 GLS Airport
ID # 1 (j)
DISC N/A N/A N/A N/A N/A Y 1000
243 GLS Runway
Selection (j)
DISC N/A N/A N/A N/A N/A Y 1000
247 Horizontal
Pos. FOM
BNR NM (c) 16 18
≅6.10E-5
Y 100
254 GBAS ID (j) DISC N/A N/A N/A N/A N/A Y 1000
255 GLS Airport
ID #2 (j)
DISC N/A N/A N/A N/A N/A Y 1000
Figure A-13. ARINC Output Data (GLS bus) (Sheet 3 of 4)
