INSTALLATION MANUAL
CMA-5024 GLSSU
This document includes Proprietary Information and shall not be reproduced or communicated to third party
without prior written permission by CMC Electronics Inc.
Page A.24
November 21, 2008
Oct.
Label
429
Parameter
Signal
Format
Units
Pos.
Sense
Range (r)
Sig.
Bits
Res. (r)
SDI
Pres.
Nom. Tx
(a)
260 Date (j) BCD D:M:
YR
(c) N/A 6 1 DAY Y 100
263 Approach ID
#1 (j)
DISC N/A N/A N/A N/A N/A Y 200
264 Approach ID
#2 (j)
DISC N/A N/A N/A N/A N/A Y 200
273 GLSSU Status
(j)
DISC N/A N/A N/A N/A N/A Y 100
305 (e) SBAS PA
Mode & SP
Selection (j)
DISC N/A N/A N/A N/A N/A Y 200
306 (e) CRC #1 (j) DISC N/A N/A N/A N/A N/A Y 500
307 (e) CRC #2 (j) DISC N/A N/A N/A N/A N/A Y 500
341 (e) SBAS Look-
Ahead HIL
BNR NM (c) 16 17
≅1.22E-4
Y 1000
342 (e) SBAS Look-
Ahead VIL
BNR Feet (c) 32,768 17 0.25 Y 1000
343 Dest HIL (j) BNR NM (c) 16 11 7.8125E-3 Y 500
347 Alt HIL (j) BNR NM (c) 16 11 7.8125E-3 Y 500
352 Maintenance
Discrete 1 (j)
DISC N/A N/A N/A N/A N/A Y 1000
354 Counter (o) BNR Second (c) 262,144 18 1 Y 1000
355 GNSS Fault
Summary (j)
DISC N/A N/A N/A N/A N/A Y 1000
356 Maintenance
Message (j)
ISO#5 N/A N/A N/A N/A N/A N On Call
(q)
370 GPS Height BNR FT UP ±131,072 20 0.125 N 100
371 (e) Total Power
On Time
BNR Hours (c) 0-99,999 18 0.5 Y 1000
373 (e) Power On
Time Since
Last Service
Shop Visit
BNR Hours (c) 0-99,999 18 0.5 Y 1000
375 (e) Total Flight
Cycles
BNR Flights (c) 0-99,999 18 1 Y 1000
376 (e) Total Flight
Cycles Since
Last Service
Shop Visit
BNR Flights (c) 0-99,999 18 1 Y 1000
377 Equipment ID
(j)(aa)
DISC N/A N/A N/A N/A N/A Y 1000
Figure A-13. ARINC Output Data (GLS bus) (Sheet 4 of 4)
34-52-81-1
