20.1.7 Log OEM Codes

Enables or disables the log function of EFI codes as OEM codes (if not already legacy converted).

20.1.8 Convert OEM codes

Enabling or disabling the conversion of EFI status codes to standard SMBIOS

types (not all may be translated).

20.1.9 View SMBIOS Event Log

Opens the submenu to show all SMBIOS event log entries present.
