Copyright © 2014 congatec AG IGX1m02 19/134
3.6 Onboard Components
Intrusion Backlight Control
Drive Power
LPT
USB 2.0
Chassis Fan
2x SO-DIMM
Front panel
2x USB 2.0
COM3
Buzzer
Feature / GPIO
mSATA
TPM
CPU
SATA1 (Gen 3)
(shared with mSATA)
mini PCIe
SATA0 (Gen 3)
CPU Fan
PCIe x4 (Gen 2)
LVDS 2x24 Bit
SPDIF
DC Input
DC Input
Front panel Audio
2x USB 3.0
