Copyright © 2014 congatec AG IGX1m02 132/134
conga-IGX NEC 104PW201
Inverter-Connector JST PHR-8 53261-0871 (MOLEX)
Signal Symbol Pin Pin Symbol
Ground GND 1
◄▪▪▪▪▪►
3, 4
2)
GND
Ground GND 2
◄▪▪▪▪▪►
7 BRTH
Backlight Brightness CTRL tbd 3
◄▪▪▪▪▪►
6 BRT_Adj
Power 5V VCC 4
Power 5V VCC 5
Backlight On/Off Control BL On/Off 6
◄▪▪▪▪▪►
5 BL On/Off
Power 12V +12V 7
◄▪▪▪▪▪►
1 DC-In / 12V
Power 12V +12V 8
◄▪▪▪▪▪►
2 DC-In / 12V
2)
if impossible then connect pin 3 only
24.8.2 Inverter Cable Plan
24.8.3 Inverter Pinout NEC 104PW201
Pin Symbol Remark
1-2 VDDB Power supply
3-4 GNDB Ground
5 BRTC
"Backlight ON/OFF
Open or High: ON
Low: OFF"
6 BRTI Luminance control terminal
7 BRTH Luminance control terminal
8 AM Altert signal for malfunction
