Congatec conga-IGX - Inverter Cable and Pinout (GH001 HB); Inverter Cable Plan (GH001 HB); Inverter Pinout (GH001 HB)

Copyright © 2014 congatec AG IGX1m02 130/134
conga-IGX Green C&C GH001HB
Inverter-Connector JST PHR-8 53261-1090 (MOLEX)
Signal Symbol Pin Pin Symbol
Ground GND 1
◄▪▪▪▪▪►
3 GND
Ground GND 2
◄▪▪▪▪▪►
4 GND
Backlight Brightness CTRL tbd 3
◄▪▪▪▪▪►
5 BRT_Adj
Power 5V VCC 4
Power 5V VCC 5
Backlight On/Off Control BL On/Off 6
◄▪▪▪▪▪►
7 BL On/Off
Power 12V +12V 7
◄▪▪▪▪▪►
1 DC-In / 12V
Power 12V +12V 8
◄▪▪▪▪▪►
2 DC-In / 12V
24.7.2 Inverter Cable Plan
24.7.3 Inverter Pinout Green C&C GH001HB
Pin Symbol Remark
1 BRT_ADJ 0 ~ 5V
3,4,7,8 GND GND
5 BL ON/OFF CCFL Drive SIGNAL(Active HIGH)
2,6 N.C
9,10 DC-IN(Vin) DC INPUT Power (12V)
