Congatec conga-IGX - Internal USB 3.0 Ports

Copyright © 2014 congatec AG IGX1m02 45/134
7.3 Internal USB 3.0 Ports
Pin Signal Pin Signal
1 VCC AUX 2 USB3_RX negative (P2)
3 USB3_RX positive (P2) 4 GND
5 USB3_TX negative (P2) 6 USB3_TX positive (P2)
7 GND 8 Data negative (P2)
9 Data positive (P2) 10 FP Detect
11 Data positive (P3) 12 Data negative (P3)
13 GND 14 USB3_TX positive (P3)
15 USB3_TX negative (P3) 16 GND
17 USB3_RX positive (P3) 18 USB3_RX negative (P3)
19 VCC AUX 20 <Key>
Drive Power
COM 3
LPT
Front Panel
Mouse
Keyboard
Power
COM 2
DisplayPort
PCIe X4
FAN 2
1
2
Front Panel 1 = HDD_LED+
2 = Power_LED+
3 = HDD_LED-
4 = Power_LED-
5 = Reset_Switch
DC Plug Jumper Settings1 = + DC
2 = GND
12 V max. 60 Watt
19-24 V max. 100 Watt
Plug: 2.5 / 5.5 / 11 mm
Power 1 = GND
2 = GND
3 = + DC 12 / 19-24 V
4 = + DC 12 / 19-24 V
6 = Power_Switch
7 = Reset_Switch
8 = Power_Switch
9 = Reserved
Drive Power 1 = Vcc 5 V max. 2 A
2 = GND
3 = GND
4 = +12 V max. 2 A
FAN 1
SPDIF
Front Audio
mini PCIe
mSATASATA0 SATA1
LAN
2x USB 2.0
LAN
2x USB 2.0
LVDS
Backlight
TPM GPIO
Buzzer
Battery
2x USB 3.0
2x USB 2.0
LVDS
CPU
Memory Module 1 Memory Module 2
BIOS Recovery Settings
LVDS Supply Settings
USB 2.0
LVDS BL Control Settings
System Power On Settings
1
1
Fan 1 (CPU)
1 = GND
2 = 12 V PWM mode, 4..12 V 3-pin mode
3 = Sense
4 = PWM
1
Fan 2 (Chassis)
4
2
3
2
1
DC DVI-I DisplayPort
COM1 COM2
BIOS Recovery Settings
Normal Operation (default)
Normal Operation (default)
LVDS Supply Settings
LVDS BL Control Settings
System Power On Settings
Always on
BIOS Recovery / Reset to Defaults
VCC 3.3 V
(default)
VCC 5 V
Analog
(default)
PWM
