8.2 conga-IGX Sensors

Sensor 4 [Core]

(rear side below core voltage regulator coil )

Sensor 0 [AMD TSI]

(inside Processor)

Sensor 3 [Mem]

Sensor 2 [12VReg]

(close to 12V voltage regulator coil)

Sensor 1 [SIO]

(inside Super I/O)
