Disabled The serial port is not available.

Enabled The serial port is available.

17.10.2 Device Settings

Shows the base I/O address and the interrupt used for access to the parallel port.

17.10.3 Change Settings

Species which base I/O addresses and which interrupts can be used by the BIOS

or operating system for the particular serial port.

Auto

The base I/O address and the interrupt are automatically

assigned.

IO=3F8h; IRQ=4;

The base I/O address 3F8h and the interrupt 4 are

permanently assigned.

IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12;

The base I/O address is permanently assigned.

IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12;

IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12;

IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12;

The values given in the list are available for the interrupt for automatic selection

by the BIOS or the operating system.

If conicts with other devices occur, this option should be converted to Auto.

17.11 Serial Port 1 Conguration

Opens the submenu for conguration of the serial port 1 (COMB).
