8 System Monitoring
8.1 conga-IGX: Fans
TDPmax - Processor (SoC):
• 9W AMD G-Series SOC GX-210HA
• 15W AMD G-Series SOC GX-217GA
• 25W AMD G-Series SOC GX-420CA
Note
Processor Throttling is enabled @ 108°C and disabled again below 105°C. Above 115°C the processor shuts down the system. The onboard
System Monitoring implementation provides a processor Alert above 105°C.
Caution
Fans must NOT be attached or removed while the system is powered, otherwise the conga-IGX may be damaged.
Note
Fan1 PWM (4-wire) only!
Fan2: PWM (4-wire) or voltage controlled (3-wire) possible.
Selectable via BIOS Setup
Caution
Do not attach more than one fan per connector (max. 1A per connector).
