Congatec conga-IGX - Inverter Cable and Pinout Information; Inverter Cable Plan (GH093 A); Inverter Pinout (GH093 A)

Copyright © 2014 congatec AG IGX1m02 118/134
conga-IGX Green C&C GH093A
Inverter-Connector JST PHR-8 20037WR-06A00(P) (YEONHO) / EQUIVALENT
Signal Symbol Pin Pin Symbol
Ground GND 1
◄▪▪▪▪▪►
3 GND
Ground GND 2
◄▪▪▪▪▪►
4 GND
Backlight Brightness CTRL tbd 3
◄▪▪▪▪▪►
6 BRT_Adj
Power 5V VCC 4
Power 5V VCC 5
Backlight On/Off Control BL On/Off 6
◄▪▪▪▪▪►
5 BL On/Off
Power 12V +12V 7
◄▪▪▪▪▪►
1 DC-In / 12V
Power 12V +12V 8
◄▪▪▪▪▪►
2 DC-In / 12V
24.1.2 Inverter Cable Plan
24.1.3 Inverter Pinout Green C&C GH093A
Signal Symbol Remark
1,2 DC-IN(Vin) DC INPUT Power (12V)
3,4 GND GND
5 BL ON/OFF CCFL Drive SIGNAL(Active HIGHT)
6 BRT_ADJ 0 ~ 5V
