24.8 NEC NL6448BC33-63D LVDS Cable Pinout
conga-IGX NEC NL6448BC33-63D
LVDS Connector Hirose DF13-40, straight, SMT JAE FI-S20S
Signal Symbol Pin Pin Symbol
Ground GND 1
◄▪▪▪▪▪►
3 Scan direction
Ground GND 2
◄▪▪▪▪▪►
4 Colors
LVDS_Out3+ (ODD_3+) LO3+ 3
◄▪▪▪▪▪►
1 D3+
LVDS_Out7+ (EVEN_3+) LO7+ 4
LVDS_Out3- (ODD_3-) LO3- 5
◄▪▪▪▪▪►
2 D3-
LVDS_Out7- (EVEN_3-) LO7- 6
Ground GND 7
Ground GND 8
◄▪▪▪▪▪►
5 GND
LVDS_Out2+ (ODD_2+) LO2+ 9
◄▪▪▪▪▪►
9 D2+
LVDS_Out6+ (EVEN_2+) LO6+ 10
LVDS_Out2- (ODD_2-) LO2- 11
◄▪▪▪▪▪►
10 D2-
LVDS_Out6- (EVEN_2-) LO6- 12
Ground GND 13
◄▪▪▪▪▪►
11 GND
Ground GND 14
LVDS_Out1+ (ODD_1+) LO1+ 15
◄▪▪▪▪▪►
12 D1+
LVDS_Out5+ (EVEN_1+) LO5+ 16
LVDS_Out1- (ODD_1-) LO1- 17
◄▪▪▪▪▪►
13 D1-
LVDS_Out5- (EVEN_1-) LO5- 18
Ground GND 19
◄▪▪▪▪▪►
14 GND
Ground GND 20
LVDS_Out0+ (ODD_0+) LO0+ 21
◄▪▪▪▪▪►
15 D0+
LVDS_Out4+ (EVEN_0+) LO4+ 22
LVDS_Out0- (ODD_0-) LO0- 23
◄▪▪▪▪▪►
16 D0-
LVDS_Out4- (EVEN_0-) LO4- 24
Ground GND 25
◄▪▪▪▪▪►
17 GND
Ground GND 26
◄▪▪▪▪▪►
18 GND
LVDS_CLK1+ (CLK_ODD+) CLK1+
27
◄▪▪▪▪▪►
6 CLK+
LVDS_CLK2+ (CLK_EVEN+) CLK2+ 28
LVDS_CLK1- (CLK_ODD-) CLK1- 29
◄▪▪▪▪▪►
7 CLK-
LVDS_CLK2- (CLK_EVEN-) CLK2- 30
Ground GND 31
◄▪▪▪▪▪►
8 GND
Ground GND 32
DDC-Clock DDCCLK 33
DDC-Data DDCDATA 34
LCD-Power 1) +3.3V / +5V 35
◄▪▪▪▪▪►
19 VCC
LCD-Power 1) +3.3V / +5V 36
◄▪▪▪▪▪►
20 VCC
LCD-Power 1) +3.3V / +5V 37
Ground GND 38
Ground GND 39
LCD_PowerOn LCD_On 40
1) selectable via Jumper
Pin Signal Name Description
1A D3+ Pixel Data
1B GND Ground
2A D3- Pixel Data
2B GND Ground
3 DPS
"Selection of scan direction
High: Reverse scan, Low or Open: Normal scan"
4 FRC
"Selectikon of the number of colors
High: 16,777,216 colors, Low: 262,144 colors"
5 GND Ground
6 CLK+ Pixel Clock
7 CLK- Pixel Clock
8 GND Ground
9 D2+ Pixel Clock
10 D2- Pixel Clock
11 GND Ground
12 D1+ Pixel Clock
13 D1- Pixel Clock
14 GND Ground
15 D0+ Pixel Clock
16 D0- Pixel Clock
17 GND Ground
18 GND Ground
19 VCC Power supply, typ. 3.3 V / 310 mA
20 VCC Power supply, typ. 3.3 V / 310 mA
24.8.1 Panel Pinout NEC NL6448BC33-63D
