4 Heatsink/Heatpipe Installation Notes

(SATA connectors)

Due to the required dimensions of the 15W passive heatsink with heatpipes, the onboard SATA ports are covered when the device is installed.

Note

SATA cables with angle connectors can be used when utilizing a passive heatsink with heatpipes, but they must be installed before mounting

the heatsink with heatpipes.
