17.12.1 Parallel Port
Species whether the parallel port is available.
Disabled The parallel port is not available.
Enabled The parallel port is available.
17.12.2 Device Settings
Shows the base I/O address and the interrupt used for access to the parallel port.
17.12.3 Change Settings
Species which base I/O addresses and which interrupts can be used by the BIOS or operating system for the particular serial port.
Auto
The base I/O address and the interrupt are automatically assigned.
IO=378h; IRQ=5;
The basic I/O address 2F8h and the Interrupt 3 are rmly allocated.
IO=378h; IRQ=5,6,7,9,10,11,12;
The base I/O address is permanently assigned.
IO=278h; IRQ=5,6,7,9,10,11,12;
IO=3BCh; IRQ=5,6,7,9,10,11,12;
The values given in the list are available for the interrupt for automatic selection
by the BIOS or the operating system.
If conicts with other devices occur, this option should be converted to Auto.
17.12.4 Device Mode
Species whether the parallel port should be used as an input/output port or just as an output port. The ECP and EPP transfer modes permit
higher transfer speeds of 2 or 2.4 Mbyte/sec. These modes can however only be used on devices that also support these modes. In addition,
for EPP the I/O address of the parallel port must be set to 378 h or 278 h.
