24.5 Sharp LQ190 LVDS Cable Pinout
conga-IGX Sharp LQ190
LVDS Connector Hirose DF13-40, straight, SMT FI-X30SSL-HF (Japan Aviation Electronics)
Signal Symbol Pin Pin Symbol
Ground GND 1
Ground GND 2
LVDS_Out3+ (ODD_3+) LO3+ 3
◄▪▪▪▪▪►
11 RxO3+
LVDS_Out7+ (EVEN_3+) LO7+ 4
◄▪▪▪▪▪►
23 RxE3+
LVDS_Out3- (ODD_3-) LO3- 5
◄▪▪▪▪▪►
10 RxO3-
LVDS_Out7- (EVEN_3-) LO7- 6
◄▪▪▪▪▪►
22 RxE3-
Ground GND 7
◄▪▪▪▪▪►
7 GND
Ground GND 8
LVDS_Out2+ (ODD_2+) LO2+ 9
◄▪▪▪▪▪►
6 RxO2+
LVDS_Out6+ (EVEN_2+) LO6+ 10
◄▪▪▪▪▪►
19 RxE2+
LVDS_Out2- (ODD_2-) LO2- 11
◄▪▪▪▪▪►
5 RxO2-
LVDS_Out6- (EVEN_2-) LO6- 12
◄▪▪▪▪▪►
18 RxE2-
Ground GND 13
Ground GND 14
◄▪▪▪▪▪►
14 GND
LVDS_Out1+ (ODD_1+) LO1+ 15
◄▪▪▪▪▪►
4 RxO1+
LVDS_Out5+ (EVEN_1+) LO5+ 16
◄▪▪▪▪▪►
16 RxE1+
LVDS_Out1- (ODD_1-) LO1- 17
◄▪▪▪▪▪►
3 RxO1-
LVDS_Out5- (EVEN_1-) LO5- 18
◄▪▪▪▪▪►
15 RxE1-
Ground GND 19
Ground GND 20
◄▪▪▪▪▪►
17 GND
LVDS_Out0+ (ODD_0+) LO0+ 21
◄▪▪▪▪▪►
2 RxO0+
LVDS_Out4+ (EVEN_0+) LO4+ 22
◄▪▪▪▪▪►
13 RxE0+
LVDS_Out0- (ODD_0-) LO0- 23
◄▪▪▪▪▪►
1 RxO0-
LVDS_Out4- (EVEN_0-) LO4-
24
◄▪▪▪▪▪►
12 RxE0-
Ground GND 25
◄▪▪▪▪▪►
24 GND
Ground GND 26
◄▪▪▪▪▪►
25 SEL LVDS
LVDS_CLK1+ (CLK_ODD+) CLK1+ 27
◄▪▪▪▪▪►
9 RxOC+
LVDS_CLK2+ (CLK_EVEN+) CLK2+ 28
◄▪▪▪▪▪►
21 RxEC+
LVDS_CLK1- (CLK_ODD-) CLK1- 29
◄▪▪▪▪▪►
8 RxOC-
LVDS_CLK2- (CLK_EVEN-) CLK2- 30
◄▪▪▪▪▪►
20 RxEC-
Ground GND 31
Ground GND 32
DDC-Clock DDCCLK 33
DDC-Data DDCDATA 34
LCD-Power 1) +3.3V / +5V 35
◄▪▪▪▪▪►
28 Vcc
LCD-Power 1) +3.3V / +5V 36
◄▪▪▪▪▪►
29 Vcc
LCD-Power 1) +3.3V / +5V 37
◄▪▪▪▪▪►
30 Vcc
Ground GND 38
Ground GND 39
LCD_PowerOn LCD_On 40
◄▪▪▪▪▪►
26 PD
Pin Signal Name Description
1 RxO0- Negative differential input
2 RxO0+ Positive differential input
3 RxO1- Negative differential input
4 RxO1+ Positive differential input
5 RxO2- Negative differential input
6 RxO2+ Positive differential input
7 GND Ground
8 RxOC- Negative differential input
9 RxOC+ Positive differential input
10 RxO3- Negative differential input
11 RxO3+ Positive differential input
12 RxE0- Negative differential input
13 RxE0+ Positive differential input
14 GND Ground
15 RxE1- Negative differential input
16 RxE1+ Positive differential input
17 GND Ground
18 RxE2- Negative differential input
19 RxE2+ Positive differential input
20 RxEC- Negative differential input
21 RxEC+ Positive differential input
22 RxE3- Negative differential input
23 RxE3+ Positive differential input
24 GND Ground
25 SEL LVDS Select LVDS Mapping
26 PD LVDS Core Power Down
27 TST Test pin *1
28 Vcc +5V power supply
29 Vcc +5V power supply
30 Vcc +5V power supply
24.5.1 Panel Pinout Sharp LQ190
