Faulty color display often indicates an incorrectly congured LVDS mode.
FPDI 8 bit
FPDI (Flat Panel Interface) 8 bit mode is being used.
FPDI 6 bit
FPDI (Flat Panel Interface) 6 bit mode is being used.
LDI 8 bit
LDI (LVDS Display Interface) 8 bit mode is being used.
LDI 6 bit
LDI (LVDS Display Interface) 6 bit mode is being used.
17.4.5 LVDS Channel Swap
Depending on the connected LCD panel, the channels of the LVDS interface can be swapped.
Disabled
The channels of the LVDS interface are not swapped.
Enabled
The channels of the LVDS interface are swapped.
17.4.6 LVDS Backlight-Enable Polarity
Depending on the connected LCD panel, the polarity for enabling backlighting can be set.
Active High
The polarity for enabling backlighting of the LCD panel is Active High.
Active Low
The polarity for enabling backlighting of the LCD panel is Active Low.
17.4.7 LVDS Brightness Control
Determines whether the brightness of the LCD panel connected at the LVDS interface
is controlled in the BIOS setup or under the operating
system.
OS Controlled
The brightness of the LCD panel connected at the LVDS interface is controlled
under the operating system.
BIOS Controlled
The brightness of the LCD panel connected at the LVDS interface is controlled in
the BIOS setup.
