Congatec conga-IGX - Sharp LQ150 LVDS Pinout; Panel Pinout Sharp LQ150

Copyright © 2014 congatec AG IGX1m02 127/134
24.6.1 Sharp LQ150 LVDS Cable Pinout
conga-IGX Sharp LQ150
LVDS Connector Hirose DF13-40, straight, SMT DF14H-20P-1.25H (Hirose)
Signal Symbol Pin Pin Symbol
Ground GND 1
◄▪▪▪▪▪►
3 GND
Ground GND 2
◄▪▪▪▪▪►
4 GND
LVDS_Out3+ (ODD_3+) LO3+ 3
◄▪▪▪▪▪►
18 Rx3+
LVDS_Out7+ (EVEN_3+) LO7+ 4
LVDS_Out3- (ODD_3-) LO3- 5
◄▪▪▪▪▪►
17 Rx3-
LVDS_Out7- (EVEN_3-) LO7- 6
Ground GND 7
◄▪▪▪▪▪►
7 GND
Ground GND 8
LVDS_Out2+ (ODD_2+) LO2+ 9
◄▪▪▪▪▪►
12 Rx2+
LVDS_Out6+ (EVEN_2+) LO6+ 10
LVDS_Out2- (ODD_2-) LO2- 11
◄▪▪▪▪▪►
11 Rx2-
LVDS_Out6- (EVEN_2-) LO6- 12
Ground GND 13
Ground GND 14
◄▪▪▪▪▪►
10 GND
LVDS_Out1+ (ODD_1+) LO1+ 15
◄▪▪▪▪▪►
9 Rx1+
LVDS_Out5+ (EVEN_1+) LO5+ 16
LVDS_Out1- (ODD_1-) LO1- 17
◄▪▪▪▪▪►
8 Rx1-
LVDS_Out5- (EVEN_1-) LO5- 18
Ground GND 19
Ground GND 20
◄▪▪▪▪▪►
13 GND
LVDS_Out0+ (ODD_0+) LO0+ 21
◄▪▪▪▪▪►
6 Rx0+
LVDS_Out4+ (EVEN_0+) LO4+ 22
LVDS_Out0- (ODD_0-) LO0- 23
◄▪▪▪▪▪►
5 Rx0-
LVDS_Out4- (EVEN_0-) LO4- 24
Ground GND 25
Ground GND 26
◄▪▪▪▪▪►
16 GND
LVDS_CLK1+ (CLK_ODD+) CLK1+ 27
◄▪▪▪▪▪►
15 CK+
LVDS_CLK2+ (CLK_EVEN+) CLK2+ 28
LVDS_CLK1- (CLK_ODD-) CLK1- 29
◄▪▪▪▪▪►
14 CK-
LVDS_CLK2- (CLK_EVEN-) CLK2- 30
Ground GND 31
◄▪▪▪▪▪►
19 GND
Ground GND 32
◄▪▪▪▪▪►
20 GND
DDC-Clock DDCCLK 33
DDC-Data DDCDATA 34
LCD-Power 1) +3.3V / +5V 35
◄▪▪▪▪▪►
1 Vcc
LCD-Power 1) +3.3V / +5V 36
◄▪▪▪▪▪►
2 Vcc
LCD-Power 1) +3.3V / +5V 37
Ground GND 38
Ground GND 39
LCD_PowerOn LCD_On 40
Pin Signal Name Description
1 VCC +3.3V Power supply
2 VCC +3.3V Power supply
3 GND GND
4 GND GND
5 RxIN0- LVDS receiver signal CH0 (-)
6 RxIN0+ LVDS receiver signal CH0 (+)
7 GND GND
8 RxIN1- LVDS receiver signal CH1 (-)
9 RxIN1+ LVDS receiver signal CH1 (+)
10 GND GND
11 RxIN2- LVDS receiver signal CH2 (-)
12 RxIN2+ LVDS receiver signal CH2 (+)
13 GND GND
14 CK IN- LVDS receiver signal CK (-)
15 CK IN+ LVDS receiver signal CK (+)
16 GND GND
17 RxIN3- LVDS receiver signal CH3 (-)
18 RxIN3+ LVDS receiver signal CH3 (+)
19 RL/UD Horizontal/Vertical display mode select signal
20 SELLVDS LVDS SET
24.6.2 Panel Pinout Sharp LQ150
