17 Advanced Menu – Advanced system

conguration

The advanced functions which are available to the system are congured in this

menu for the advanced system conguration.

Only change the default settings if required for a special purpose.

Incorrect settings can cause malfunctions.

Advanced Menu – Advanced system

configuration

Example showing the Advanced menu
