Congatec conga-IGX - Inverter Cable and Pinout (GH001 HB); Inverter Cable Plan (GH001 HB); Inverter Pinout (GH001 HB)

134 pages

To Next Page

To Previous Page

conga-IGX Green C&C GH053A

Inverter-Connector JST PHR-8 53261-1290 (Molex) or equivalent

Signal Symbol Pin Pin Symbol

Ground GND 1

◄▪▪▪▪▪►

7 (6) GND

Ground GND 2

◄▪▪▪▪▪►

5 (8) GND

Backlight Brightness CTRL tbd 3

◄▪▪▪▪▪►

11 (2) BRT_Adj

Power 5V VCC 4

Power 5V VCC 5

Backlight On/Off Control BL On/Off 6

◄▪▪▪▪▪►

9 (4) BL On/Off

Power 12V +12V 7

◄▪▪▪▪▪►

3 (10) DC-In / 12V

Power 12V +12V 8

◄▪▪▪▪▪►

1 (12) DC-In / 12V

Pinout analog connector CN1 (mirrored to inverter spec, inverter

pinout in brackets)

24.4.2 Inverter Cable Plan

24.4.3 Inverter Pinout Green C&C GH053A

Pin Symbol Remark

2 BRT_ADJ 0 ~ 5V

1,3,5,6,8,9 GND GND

4 BL ON/OFF CCFL Drive SIGNAL(Active HIGHT)

7 N.C

10,11,12 DC-IN(Vin) DC INPUT Power (12V)

Note: Mirrored Pinout
