Standard Parallel

Port Mode The standard mode will be used for the parallel port.

EPP Mode

Fast transfer mode (up to 2 MByte/sec), data output and data reception are

possible. The mode requires a

peripheral device which supports the EPP

(Enhanced Parallel Port) mode.

ECP Mode

Fast transfer mode (up to 2.4 MByte/sec), data output and data reception are

possible. The mode requires a

peripheral device which supports the ECP

(Extended Capability Port) mode. The necessary DMA channel is

determined

by the system.

EPP Mode & ECP

Mode Both transfer modes are available.

17.13 Network Stack

Species whether the UEFI Network Stack is available for network access under UEFI. If the

UEFI Network Stack is disabled, UEFI installation

via PXE is not possible, for example.

Disabled

The UEFI Network Stack is not available.

Enabled

The UEFI Network Stack is available.

17.13.1 Ipv4 PXE Support

Species whether PXE UEFI Boot via Ipv4 is available for installation of

operating systems in UEFI mode.

Disabled PXE UEFI Boot via Ipv4 is not available.

Enabled PXE UEFI Boot via Ipv4 is available.

17.13.2 Ipv6 PXE Support

Species whether PXE UEFI Boot via Ipv6 is available for installation of

operating systems in UEFI mode.

Disabled PXE UEFI Boot via Ipv6 is not available.

Enabled PXE UEFI Boot via Ipv6 is available.
