Copyright © 2014 congatec AG IGX1m02 28/134
5.5 LVDS Timing & Screen Resolution
There are 9 default LVDS settings available:
• BIOS Setup Advanced - LVDS Cong Select
Note
Option 10 (LVDS adjusted Parameters) becomes visible after once running the “LVDS Tool” for implementing customized LVDS settings.
“Non-EDID Support” must be set to <Enabled> for standard LVDS displays without DDC (EDID) interface.
