Congatec conga-IGX - Inverter Cable and Pinout (PS-DA0412-05); Inverter Cable Plan (PS-DA0412-05); Inverter Pinout (PS-DA0412-05)

Copyright © 2014 congatec AG IGX1m02 126/134
conga-IGX PowerSystems PS-DA0412-05
Inverter-Connector JST PHR-8 B8B-PH-K (JST or equal)
Signal Symbol Pin Pin Symbol
Ground GND 1
◄▪▪▪▪▪►
7 (6) GND
Ground GND 2
◄▪▪▪▪▪►
5 (8) GND
Backlight Brightness CTRL tbd 3
◄▪▪▪▪▪►
11 (2) BRT_Adj
Power 5V VCC 4
Power 5V VCC 5
Backlight On/Off Control BL On/Off 6
◄▪▪▪▪▪►
9 (4) BL On/Off
Power 12V +12V 7
◄▪▪▪▪▪►
3 (10) DC-In / 12V
Power 12V +12V 8
◄▪▪▪▪▪►
1 (12) DC-In / 12V
Pinout analog connector CN1 (mirrored to inverter spec, inverter pinout in brackets)
24.5.2 Inverter Cable Plan
24.6 Inverter Pinout PowerSystems PS-DA0412-05
Pin CN-1 Symbol Remark
1;2;3 Vin 10.8 ~ 13.2 Vdc
4;5;6 GND
7 Vbr 0 ~ 3.0 Vdc
8 Vrm t 0 ~ 0.5 = OFF / 3.3 ~ Vin = ON
