CPG Compuprint SP 40 - Step by Step T&D Mode Sequential Table; Table 5.3 Step by Step USER Complete Sequential Actions

Maintenance Manual SP 40
Rev. 005
91
Chapter 5
Test & Diagnostic
5.6 Step By Step T&D Mode Sequential Table
This is a table of the whole T&D USER procedure in sequential Step By Step mode.
The column have these meaning:
1) T&D SbS Phases
2) Messages on the Operator Panel with Display.
3) The same message converted on the leds for the standard Operator Panel.
4) Operator panel key to be pressed.
5) Action done by the operator panel key pressure.
T&D SbS PHASE DISPLAY MESSAGE LEDS PUSHED KEY KEY's ACTION
Initialization phase “STARTING”
¡
¡
¡
¡
ON LINE
+
STATION 1
Run T&D
Initialization phase “STARTING”
¥
l
¡
l
Initialization phase “INIT”
l
l
¡
l
Initialization phase “INIT”
l
l
l
l
Choice of mode
SBS= Step by Step
CMPL=complete
LST=complete
"SBS CMPL LST”
£
¥
¡
£
STATION 1
(in 2 sec)
Choose of Step by
Step Mode
NVM WRITING Test
(available only in
Step by Step mode)
“T&D 02 S_B_S”
l
l
¡
l
ON LINE
or
STATION 1
or
STATION 2
ON LINE to run
STATION 1
to decrement test
STATION 2
to increment test
“REPT LOOP SKIP”
£
¥
l
£
ON LINE
or
STATION 1
or
STATION 2
ON LINE to loop
STATION 1
to repeat the test
STATION 2
to skip the test
NVM Checksum
Test
“T&D 03 S_B_S”
l
l
¡
¡
ON LINE
or
STATION 1
or
STATION 2
ON LINE to run
STATION 1
to decrement test
STATION 2
to increment test
Table 5.3 Step by Step T&D USER Sequential Actions
