Maintenance Manual SP 40
Rev. 005
56
Chapter 3
Operabilty and Configuration
Setup Parameter Values Description
RESTORE TO MFG No*
all
config
progr. 1, progr. 2
The selected values are not set to factory defaults.
The values set in all printer setups are reset to factory default values.
The values set in the configuration setup are reset to factory default values.
The values set in the corresponding program setup are reset to the factory
default values.
RIBBON REPLACED No*, yes Selects yes when the ribbon has been replaced to reset the ribbon life counter.
PROGRAM progr. 1*, progr. 2,
on interface
Defines the default Program Setup. Selecting progr.1 or progr.2 the setup
parameters set in the corresponding Program Setup are set.
Selecting on interface the printer matches the Program 1 settings with the data
arriving on the Centronics interface, and the Program 2 settings with the data it
receives from the serial interface. When changing from one interface to the
other, the default values are set for the corresponding Program Setup.
ERROR BUZZER Disabled, enabled* Selects or not the buzzer.
JOB BUZZER no beep*, 1 beep, continuous Selects the behavior of the buzzer when a new print job starts: no signal (no
beep), one beep (1 beep) or a continuous signal (continuous).
INTERFACE TYPE parallel, serial, lan, automatic* Selects the interface type. Selecting ‘automatic’ the interface type is selected
between serial, parallel or lan by the printer depending on data coming from
host.
IBM FINANCIAL No*, honorCTS, ignoreCTS This setting is significant only if the 4722 or 9068 protocol have been selected.
It sets the CTS signal, that may be considered or not.
INPUT BUFFER 1 Kb, 8 Kb*, 16 Kb, 32 Kb, 64Kb Selects the buffer size.
IGNORE PE disabled, enabled* Selects the printer signals the paper empty condition (disabled) or not
(enabled).
AUTOFEED SIGNAL Disabled*, enabled The parallel interface uses (enabled) or not use (disabled) the AUTOFEED
signal.
SLCT-IN SIGNAL Disabled*, enabled The parallel interface uses (enabled) or does not use (disabled) the SELECT-IN
signal.
BUFFER CONTROL DTR+SRTS*, SRTS, XON/XOFF,
ETX/ACK, XON/XOFF+DTR+SRTS
Selection of the buffer protocol.
ROBUST XON disabled, enabled* Perform the Robust XON (enabled) or not (disabled).
WORD LENGTH 7 bit, 8 bit* Sets the number of the data bits.
BAUD RATE 1200, 2400, 4800, 9600*, 19200,
38400 bps
Sets the data transfer rate.
PARITY BIT even, odd, space, mark, none* Selects the number of stop bits.
STOP BIT 1*, 2 Selects the parity control for the data.
COPIES No, yes* When yes sets an higher impact force of the print head for multicopy media.
LOW NOISE No*, yes When yes sets a double pass of the printout each one with a reduced number
of dots.
Table 3.3 - Configuration Form Parameters description
