Maintenance Manual SP 40

Rev. 005

112

Chapter 5

Test & Diagnostic

==================== T&D LOG FILE ====================

Assembly: Not exec (ex. 0)

Running: Not exec (ex. 0 Loop 0 - Pg r 0 v 0)

Verify: Not exec (ex. 0)

--------- DOE_config --------------

0x408d018 : fc 00 00 00 01 00 00 1f 00 14 00 f8 00 f8 00 f8 ,,,,,,,,,,,,,,,,

0x408d028 : 00 f8 00 f8 00 f8 00 7e 02 34 00 00 00 1e 18 10 ,,,,,,,,,,,,,,,,

0x408d038 : 18 1c 14 14 fa 00 00 00 00 00 00 90 02 00 00 00 ,,,,,,,,,,,,,,,,

0x408d048 : 00 00 00 00 00 00 07 af 00 00 00 00 00 00 00 00 ,,,,,,,,,,,,,,,,

0x408d058 : 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ,,,,,,,,,,,,,,,,

--------- Current Pwm Adj ----------

S1 16, S2 24, S3 28, S4 24, S5 20, S6 20, S8 30

------------------------------------------------------

Fig. 5.12 Example of T&D 12 Log File (without errors)

==================== T&D LOG FILE ====================

Assembly: Not exec (ex. 0)

Running: Not exec (ex. 0 Loop 0 - Pg r 0 v 0)

Verify: Not exec (ex. 0)

---------- Error report ----------

01 | VERIFY | 06 | 00 | 01 |

02 | VERIFY | 06 | 00 | 01 |

03 | VERIFY | 06 | 00 | 01 |

04 | VERIFY | 09 | 02 | 01 |

05 | VERIFY | 06 | 00 | 01 |

06 | VERIFY | 10 | 02 | 01 |

07 | VERIFY | 07 | 01 | 03 |

08 | VERIFY | 06 | 00 | 01 |

09 | VERIFY | 06 | 00 | 01 |

10 | VERIFY | 06 | 00 | 01 |

11 | VERIFY | 06 | 00 | 01 |

------->> Log error overflow <<----
