Maintenance Manual SP 40
Rev. 005
111
Chapter 5
Test & Diagnostic
5.12 Log File Printout (T&D 12)
This test is for MFG site only.
It prints the following three basic informations:
1) LOG FILE
Reports the evolution and the results of the different phases of the T&D executed during the life of the printer, until
the basic controller is replaced.
Remark: In the Step by Step mode the log is not saved and no informations are registered.
For the other phases used in MFG only are stored the following informations:
• Execution status:
Not executed = not-executed phase
Executed = executed phase (at least 1 time)
Current = phase running
• Number of executions.
Up to 11 errors are saved which reported for each one: phase in execution during the error, test in error,
ORU and error code.
The nvm area containing the log can be cancelled only in the assembly phase.
The informations related to the execution status log are printed on the standard pattern printout and are
sent to the serial interface (monitor as described in chapter 5.11) at the beginning of the T&D launch.
In the T&D10 the string is:
T&D Log: Assembly: <St>(ex. #) - Running: <St>(ex. # lp. #) - Verify: <St>(ex. #)
St can be : Yes (executed), No (not-executed), Cur (running), KO (error)
# is the number of execution or the Loop in running phase (mfg only).
2) DOE_config
The overall adjustments parameters area of NVM is printed for R&D analisys.
3) CURRENT PWM ADJ
The values of the pwm test for the sensors are printed.
These valuers are the same printed in the T&D10.
The complete report is sent to the serial monitor at the end of the T&D12 and can be printed if a sheet is loaded
within 10 seconds.
