Maintenance Manual SP 40
Rev. 005
101
Chapter 5
Test & Diagnostic
O.R.U. Reference
0 Pwa
1 Operator Panel
2 Sensors
3 Mechanical
4 Eproms / Flash / Rom
5 Supervisor (s/w)
6 LAN
7 USB
8 Option (MSRW/ MICR)
9 Scanner (not used)
Table 5.9 T&D O.R.U. Codes
Error Code Error Meaning
1 Sensors S1 / S2 (PPS)
2 Sensors S3 / S6 (CSLS)
3 Sensor S8
4 Threshold S8
5 Sensor S8
6 Sensor ribbon
Table 5.10 T&D Common errors (sensors) Codes
Error Code Error Meaning
1 Movement (generic)
2 Paper movement
3 First Line out of tolerance
4 Engine general error
9 Thermal sensor in print head out of tolerance (10°C ÷ 60°C)
10 Dynamic error on thermal sensor in print head
11 Data integrity
12 Not used
13 Selector Error
14 Not used
Table 5.11 T&D Common errors (mechanical) Codes
