Maintenance Manual SP 40
Rev. 005
100
Chapter 5
Test & Diagnostic
5.8 T&D Errors Codes
The executed tests are 11.
The table below shows the complete list of tests with description and the O.R.U. (Optimum Replaceable
Unit) under test.
Nº Test Description Error Code Error Description
1 Reserved - -
2 Test complete E
2
PROM 1 Writing error
2 Reading error
3 Checksum E
2
PROM 2 Checksum error
4 Test Optional i/f 1 USB error
3 LAN: initialization
4 LAN: command
5 LAN: receive command
6 LAN: receive reply
7 LAN: trasmission command
8 LAN: trasmission reply
9 LAN: generic test channel
10 LAN: internal ram
11 LAN: ethernet test
5 Test loop i/f serial 1 test pattern rx-tx
2 loop dtr – dsr
3 loop rts - cts
4 loop srts - dcd
6 Test loop parallel 1 loop busy strobe
2 loop slct init
3 loop ack autofeed
4 loop pe^flt – sctin
5 test pattern rx-tx
7 Test panel operator 1 Key 1 (ON LINE)
2 Key 2 (STATION 1)
3 Key 3 (STATION 2)
7 General error
8 Test cover 1 Cover closed
2 Cover open
9 Printing Adjustments * Common errors tables
10 Standard Pattern Module * Common errors tables
11 Scanner Error (not used) 1 Front error
2 Rear error
3 Front/Rear error
* Common errors tables
12 Log File * Common errors tables
13 Test life counter reset - -
Table 5.8 T&D Error Codes
